180 KW Solar Project for Viraj Cottex Parbhani

Client: Mr. Nikhil Chaudary (Viraj Cottex)
Location: Parbhani, Maharashtra
Project Capacity: 180 kW

Project Overview:

Our journey with Viraj Cottex began through a recommendation from Mr. Subhash Dwarkadas Chaudhari, who was impressed with our previous installations at Neo Prime (400 kW) and Amit Cot Fiber (1000 kW). After witnessing the high-quality performance of these projects, Mr. Chaudhari, the owner of Viraj Cottex, decided to award the 180 kW solar project to Chirayu Power Pvt. Ltd. in Parbhani, Maharashtra.

The installation had to be executed during the peak cotton ginning season, which meant the project had to be carried out without disrupting the ongoing factory operations. Our team ensured that the project was completed seamlessly with zero downtime for the client’s production.

This project was particularly challenging due to the flammable cotton fibers in the area, which required extra precautions during welding and fabrication. We implemented strict safety protocols to ensure the safety of our workforce and the facility. No incidents occurred during the execution, showcasing our commitment to both safety and quality.

Technical Details for the Solar System:

• PV Modules (Solar Panels):
  • Waaree 545 Wp Mono + PERC + Half Cut Cells + Monofacial Panels.
  • Total Panels Installed: 330 Nos.
• Inverter:
  • SolarEdge Inverter
    • 100 kVA x 1 Nos.
    • 33 kVA x 1 Nos.
• Power Optimizer:
  • S1200 (2:1 DC to DC Optimizer)
  • Warranty: 25 Years

Key Features of the Solar Solution

1. High-Efficiency Waaree Panels:

• • The system uses Waaree 545 Wp Mono + PERC + Half Cut Cells + Monofacial Panels, with a total of 330 panels installed, offering high energy generation and long-lasting performance in challenging conditions.

2. SolarEdge Inverters:

• • The system includes SolarEdge inverters, offering efficiency, panel-level monitoring, and maximum system reliability.

3. Wind-Resistant Mounting Structure:

• • • The solar mounting structure is designed to withstand winds up to 150 km/h, ensuring structural durability in high-wind areas. The system utilizes an aluminum short rail structure that is securely pasted on the roof for leakproof installation.

4. Safety Features:

• • GI walkways and MS-coated railings have been provided to ensure safe access for routine maintenance, while also adhering to the highest safety standards during installation and operation.

5. Earthing and Lightning Protection:

• • The system uses pipe-in-pipe chemical earthing and ESE Lightning Arrestors, providing optimal protection against electrical faults and lightning strikes.

6. AC & DC Cables:

• • TUV-certified cables are used for both AC and DC connections, ensuring safe and reliable electrical connections for the solar system.

7. Water Pipeline for Cleaning:

• • A CPVC water pipeline system is provided for panel cleaning, ensuring maximum performance and long-term efficiency of the system.

Performance and Benefits

• Annual Energy Generation:
  The 180 kW solar system generates 2.50 Lakh units annually, reducing the cold storage facility's reliance on grid power.
• Annual Savings:
  The system saves ₹25 Lakh per year, providing financial relief to the client and allowing for reinvestment in business growth.
• Environmental Impact:
  The solar installation helps offset carbon emissions equivalent to 2,500+ trees, contributing to a greener future.

Conclusion

The 180 kW solar project for Viraj Cottex is an excellent example of how solar energy solutions can be seamlessly integrated into high-demand industrial environments. Despite the challenges of cotton ginning and the harsh environmental conditions, Chirayu Power Pvt. Ltd. successfully delivered a high-performance solar energy solution that meets the client’s needs for sustainability and cost savings.

The successful completion of this project underscores Chirayu Power’s commitment to providing cost-effective, sustainable energy solutions to our clients while helping them achieve their long-term sustainability goals.

For more information or to schedule a site visit, contact Chirayu Power Pvt. Ltd. today!

Performance Recap:

• Annual Generation: 2.50 Lakh units/year
• Annual Savings: ₹25 Lakh
• Carbon Offset: Equivalent to 2,500+ trees saved
